Product Summary

DESCRIPTION:The TDA7265 is class AB dual Audio power amplifier assembled in the Multiwatt package, specially designed for high quality sound application
as Hi-Fi music centers and stereo TV sets

Parametrics

ABSOLUTE MAXIMUM RATINGS
VS DC Supply Voltage ±25 V
IO Output Peak Current (internally limited) 4.5 A
Ptot Power Dissipation Tcase = 70°C 30 W
Top Operating Temperature -20 to 85 °C
Tstg, Tj Storage and Junction Temperature -40 to +150 °C

Features

(1)WIDE SUPPLY VOLTAGE RANGE (UP TO±25V ABS MAX.);
(2)SPLIT SUPPLY;
(3)HIGH OUTPUT POWER 25 + 25W @ THD =10%, RL = 8Ω, VS = +20V; (4)NO POP AT TURN-ON/OFF;
(5)MUTE (POP FREE);
(6)STAND-BY FEATURE (LOW Iq);
(7)SHORT CIRCUIT PROTECTION;
(8)THERMAL OVERLOAD PROTECTION

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TDA7265
TDA7265
STMicroelectronics
Audio Amplifiers 25W Stereo Amplifier
Data Sheet
0-1: $3.39
1-10: $2.74
10-100: $2.44
100-250: $2.18
TDA7265A
TDA7265A
STMicroelectronics
Audio Amplifiers 25 25W STEREO AMP Mute ST-BY AB DUAL
Data Sheet
0-295: $2.60
295-500: $2.37
500-1000: $2.06
1000-2000: $1.99
TDA7265B
TDA7265B
STMicroelectronics
Switching Converters, Regulators & Controllers 30W 30W Stereo AMP Class AB Dual 35V
Data Sheet
0-285: $2.02
285-500: $1.82
500-1000: $1.53
1000-2000: $1.49
