Product Summary
DESCRIPTION:Production is strictly controlled and follows an extensive set of instructions established for reproducibility. A homogeneous film of metal alloy is deposited on a high grade
ceramic substrate and conditioned to achieve the desired temperature coefficient. A special laser is used to achieve the target value by smoothly cutting a meander groove in the resistive layer without damaging the ceramics. A further conditioning is applied in order to stabilize the trimming result. The resistor elements are covered by a protective
coating designed for electrical, mechanical and climatic protection. The result of the determined production is verified by an extensive testing procedure on 100 % of the individual
chip resistors. This includes pulse load screening for the elimination of products with a potential risk of early life failures according to EN 140401-801, 2.1.2.2. Only accepted products are laid directly into the tape in accordance with
EN 60286-3
Parametrics
Power Rating(s) 1/16W
Resistance 1kohm
Tolerance (+ or -) 0.1%
Temperature Coefficient ±25
Package / Case 0402
Packaging Tape and Reel
Operating Temp Range -55C to 125C
Features
FEATURES
(1) Excellent overall stability at different environmental conditions 0.05 % (1000 h rated power at 70 °C);
(2) Low temperature coefficient and tight tolerances (± 0.1 %;± 10 ppm/K);
(3) Metal film layer on high quality ceramic;
(4) SnPb termination plating, minimum 6 % Pb
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TNPW04021K00BETD |
Vishay |
Thin Film Resistors - SMD 1Kohms .5% 25ppm |
Data Sheet |
|
|
||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||
|
TNPW040211K5BEED |
|
RES 11.5K OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
|
TNPW040211K5BETD |
|
RES 11.5K OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
|
TNPW040211K8BEED |
|
RES 11.8K OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
|
TNPW040211K8BETD |
|
RES 11.8K OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
|
TNPW0402120RBEED |
|
RES 120 OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
|
TNPW0402120RBETD |
|
RES 120 OHM 1/16W 0.1% 0402 |
Data Sheet |
|
|
||||||||||
