2SC5386

transistor silicon NPN triple diffused mesa type, 1500V, 16A, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.37~0.42 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.37~0.42

PartNumber:: 2SC5386

Brand:: Toshiba Semiconductor - Toshiba | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Chaney's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-04

From Other Seller

Part Number:2SC5386
US $0.37 - 0.42
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
iphone5 data cable

US $4.00 - 5.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 2SC5386 is a transistor silicon NPN triple diffused mesa type. And applications of the 2SC5386 include: high resolution display, color TV and high speed switching.

Parametrics

2SC5386 absolute maximum ratings: (1) collector-base voltage, VCBO: 1500V; (2) collector-emitter voltage, VCEO: 600V; (3) emitter-base voltage VEBO: 5V; (4) collector current DC IC: 8A, Pulse ICP: 16A; (5) base current IB: 4A; (6) collector power dissipation (TC=25°C) PC=50W; (7) Junction Temperature Tj: 150°C; (8) Storage Temperature Tstg: -55 to 150°C.

Features

2SC5386 features: high voltage VCBO=1500V; (2) Low Saturation VCE(sat) =3V (Max.) ; (3) High speed tf: 0.15uS (Typ.) ; (4) Colletor metal (fin) is fully covered with mold resin.
