Product Summary
The 12-channel AD8804ARZ provides independent digitally controllable voltage outputs in a compact 20-lead package. The AD8804ARZ is ideal for dc voltage adjustment applications. The AD8804ARZ is available in the 20-pin plastic DIP, the SOIC-20 surface mount package, and the 1mm thin TSSOP-20 package. Applications of the AD8804ARZ include: Automatic Adjustment Trimmer Replacement, Video and Audio Equipment Gain and Offset Adjustment and Portable and Battery Operated Equipment.
Parametrics
AD8804ARZ absolute maximum ratings (TA = +25°C, unless otherwise noted) : (1) VDD to GND: 0.3V, +8V; (2) VREFX to GND: 0V, VDD; (3) Outputs (Ox) to GND: 0V, VDD; (4) Digital Input Voltage to GND: 0V, 8V; (5) Operating Temperature Range: -40 to +85°C; (6) Maximum Junction Temperature (TJ MAX) : -65°C to +150°C; (7) Lead Temperature (Soldering, 10 sec) : +300°C; (8) Package Power Dissipation: TJ MAX-TA)/θJA.
Features
AD8804ARZ features: (1) Low Cost; (2) Replaces 12 Potentiometers; (3) Individually Programmable Outputs; (4) 3-Wire SPI Compatible Serial Input; (5) Power Shutdown <55 mWatts Including IDD & IREF; (6) Midscale Preset, AD8802; (7) Separate VREFL Range Setting, AD8804; (8) +3 V to +5 V Single Supply Operation; (9) APPLICATIONS; (10)Automatic Adjustment; (11)Trimmer Replacement; (12) Video and Audio Equipment Gain and Offset Adjustment; (13) Portable and Battery Operated Equipment.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8804ARZ |
|
IC DAC 8BIT 12CH W/SD 20SOIC |
Data Sheet |
|
|
||||||||||||||||||
|
AD8804ARZ-REEL |
|
IC DAC 8BIT 12CH W/SD 20SOIC |
Data Sheet |
|
|
||||||||||||||||||
