Product Summary

General Description:The DS7830/DS8830 is a dual differential line driver that also performs the dual four-input NAND or dual four-input AND function.
TTL (Transistor-Transistor-Logic) multiple emitter inputs allow this line driver to interface with standard TTL systems.The differential outputs are balanced and are designed to drive long lengths of coaxial cable, strip line, or twisted pair transmission lines with characteristic impedances of 50Ω to 500Ω. The differential feature of the output eliminates troublesome ground-loop errors normally associated with single-wire transmissions.

Parametrics

Absolute Maximum Ratings :
VCC : 7.0V
Input Voltage : 5.5V
Storage Temperature :-65℃ to +150℃
Lead Temperature (Soldering, 4 sec.) :260℃
Output Short Circuit Duration (125℃) 1 second
Maximum Power Dissipation (Note 1) at 25℃
Cavity Package :1308 mW
Molded Package :1207 mW

Features

Features
 Single 5V power supply
 Diode protected outputs for termination of positive andnegative voltage transients
 Diode protected inputs to prevent line ringing
 High speed
 Short circuit protection
