Product Summary
Description: Designed with the P6 and pentium in mind,the Harris Synchro-FET tm family provides a new approach for implementing a synchronous rectified buck switching regulator,
Parametrics
Absolute Maximum Ratings
Supply Voltage,Vcc.......................................+16V
Input Voltage Vin........................................+7V
Features
Feature:
1. Complementary Drive,Half-Bridge Power NMOS
2.Use with Low-Cost Single-Output PWM Controllers
3.Improve Efficiency Over Conventional Buck Converter With Schottky Clamp
4.Minimum Deadtime Provided by Adaptive Shoot-Through Protection Elimunates External Schottky.
5.Grounded Case for Low EMI and Simple Heatsinking
6.Low Operating Current
7.Frequency Exceeding 1MHz
8.Dual Polarity Options
9.All Pins Surge Protected
