Product Summary

description/ordering information:These devices consist of two independent, high-gain, frequency-compensated operational
amplifiers designed to operate from a single supply over a wide range of voltages. Operation from split supplies also is possible if the difference between the two supplies is 3 V to 32 V (3 V to 26 V for the LM2904), and VCC is at least 1.5 V more positive than the input common-mode voltage. The low supply-current drain is independent of the magnitude of the supply
voltage. Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational amplifier circuits that now can be implemented more easily in single-supply-voltage systems. For example,
these devices can be operated directly from the standard 5-V supply used in digital systems and easily can provide the required interface electronics without additional ±5-V supplies

Parametrics

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
Supply voltage, VCC (see Note 1) ±16 or 32 ±13 or 26 V
Differential input voltage, VID (see Note 2) ±32 ±26 V
Input voltage, VI (either input) -0.3 to 32 -0.3 to 26 V
Operating virtual junction temperature, TJ 150 150 °C
Case temperature for 60 seconds FK package 260 °C
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds JG package 300 300 °C
Storage temperature range, Tstg -65 to 150  -65 to 150 ℃

Features

 Wide Supply Range:
  Single Supply . . . 3  V  to  32  V(26 V for LM2904)
  or Dual Supplies . . . ±1.5 V to ±16 V(±13 V for LM2904)
 Low Supply-Current Drain, Independent of Supply Voltage . . . 0.7 mA Typ
 Common-Mode Input Voltage Range Includes Ground, Allowing Direct Sensing Near Ground
 Low Input Bias and Offset Parameters:
  Input Offset Voltage . . . 3  mV  Typ A Versions . . . 2  mV  Typ
  Input Offset Current . . . 2  nA  Typ
  Input Bias Current . . . 20 nA Typ A Versions . . . 15 nA Typ
 Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . 32  V (26 V for LM2904)
 Open-Loop Differential Voltage Amplification . . . 100 V/mV Typ
 Internal Frequency Compensation
