Product Summary

Description:The MCP73831/2 devices are highly advanced linear charge management controllers for use in space-limited, cost-sensitive applications. The MCP73831/2 are
available in an 8-Lead, 2 mm x 3 mm DFN package or a 5-Lead, SOT23 package. Along with their small physical size, the low number of external components required make the MCP73831/2 ideally suited for portable applications. For applications charging from a USB port, the MCP73831/2 adhere to all the specifications governing the USB power bus.The MCP73831/2 employ a constant-current/constantvoltage charge algorithm with selectable preconditioning and charge termination. The constant voltage regulation is fixed with four available options: 4.20V,4.35V, 4.40V or 4.50V, to accommodate new, emerging battery charging requirements. The constant current value is set with one external resistor. The
MCP73831/2 devices limit the charge current based on die temperature during high power or high ambient conditions. This thermal regulation optimizes the charge cycle time while maintaining device reliability. Several options are available for the preconditioning threshold, preconditioning current value, charge termination value and automatic recharge threshold. The
preconditioning value and charge termination value are set as a ratio, or percentage, of the programmed constant current value. Preconditioning can be disabled. Refer to Section 1.0 “Electrical Characteristics” for available options and the  “Product
Identification System” for standard options. The MCP73831/2 devices are fully specified over the ambient temperature range of -40°C to +85°C

Parametrics

Absolute Maximum Ratings?
VDD...................................................................................7.0V
All Inputs and Outputs w.r.t. VSS ............... -0.3 to (VDD+0.3)V
Maximum Junction Temperature, TJ............Internally Limited
Storage temperature .....................................-65°C to +150°C
ESD protection on all pins:
Human Body Model (1.5 kΩ in Series with 100 pF).......≥ 4 kV
Machine Model (200 pF, No Series Resistance) .............400V

Features

Features:
? Linear Charge Management Controller:
- Integrated Pass Transistor
- Integrated Current Sense
- Reverse Discharge Protection
? High Accuracy Preset Voltage Regulation: + 0.75%
? Four Voltage Regulation Options:
- 4.20V, 4.35V, 4.40V, 4.50V
? Programmable Charge Current
? Selectable Preconditioning
? Selectable End-of-Charge Control
? Charge Status Output
- Tri-State Output - MCP73831
- Open-Drain Output - MCP73832
? Automatic Power-Down
? Thermal Regulation
? Temperature Range: -40°C to +85°C
? Packaging:
- 8-Lead, 2 mm x 3 mm DFN
- 5-Lead, SOT23
