Product Summary

MDM connectors are used in applications requiring highly reliable, extremely small, lightweight connectors with higher density contact configurations than available in traditional rectangular connectors. They are available in 8 shell sizes accommodating from 9 to 100 contacts, and special arrangements of power and coaxial contacts.
These connectors are designed to meet the rapidly increasing demands for an environmental,high performance, rugged, moisture-sealed microminiature connector. This connector employs size 24 MICROPINTM/MICROSOCKET TM contacts on .050 (1.27) centers in a contact density identical to the standard MICRO-D connector serie.

Parametrics

MDM6600 Parametrics:Dielectric Withstanding Voltage:Method 3001:600 VAC at sea level 150 VAC at 70,00' altitud.
Insulation Resistance: Method 300:5,000 megohms minimum.
Thermal Shock: Method 1003. Condition A:- 550C to +1250C.
Physical Shock: Method 2004, Condition E:50 G's, 3 axes, 6 millisecond duration sawtooth puls.
Vibration: Method 2005, Condition IV:20 G's, 10-2,000 Hz. 12 hr.
Durability: 500 cycles of mating and unmating, 500 CPH max.
Moisture Resistance: Method 1002, Type II, omit steps 7a & 7b.
Salt Spray :Method 1001, Condition B 48 hours.
Contact Resistance(MIL-STD-202):Method 1001 Condition B At 3 amps At 1 milliam.
Contact Retention: Per MIL-DTL-83513.

Features

1. Aluminum shells to provide greater strength, prevent chipping, cracking or breaking, offer electromagnetic (EMI) and RFI shielding.
2. Silicone elastomer compression interfacial seal to provide a moisture and humidity seal between each contact and between contacts and shell.

Diagrams

<IMG src="http://www.seekic.com/uploadfile/ic-mfg/20127435319498.jpg" border=0>
