Product Summary

Applications :(1) Motor controls ;
(2) VVVF inverters ;
(3) Inverter-type welding MC over 18KHZ ;
(4) SMPS, Electrolysis ;
(5) UPS/EPS, Robotic.

Parametrics

Parametrics:Absolute Maximum Ratings @ Tj=25℃ (Per Leg) VCES Collector-to-Emitter Voltage TC = 25℃ 600V .VGE Gate emitter voltage ± 20V,IC Continuous Collector Current TC = 80℃ (25℃) 300 (430)A.ICP Pulsed collector current TC = 25℃ 600A.IF Diode Continuous Forward Current TC = 80℃ (25℃) 300 (430)A.IFM Diode Maximum Forward Curren TC = 25℃ 600A,tp Short circuit test, VGE = 15V, VCC = 360V TC = 150℃ (25℃) 6 (8)us.Viso Isolation Voltage test AC @ 1 minute 2500 V ,Weight Weight of Module 360 g ,Tj Junction Temperature -40 ~ 150 ℃,Tstg Storage Temperature -40 ~ 125 ℃,Md Mounting torque with screw : M6 4.0 N.m

Features

(1) Smart field stopper +Trench design technology ;
(2) Low VCE (sat) ;
(3) Low Turn-off losses ;
(4) Short tail current for over 20KHz .

Diagrams
