Product Summary
Xilinx introduces the Platform Flash series of in-system programmable configuration PROMs. Available in 1 to 32 Megabit (Mbit) densities, these PROMs provide an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bitstreams. The Platform Flash PROM series includes both the 3.3V XCFxxS PROM and the 1.8V XCFxxP PROM. The XCFxxS version includes 4-Mbit, 2-Mbit, and 1-Mbit PROMs that support Master Serial and Slave Serial FPGA configuration modes (Figure 1). The XCFxxP version includes 32-Mbit, 16-Mbit, and 8-Mbit PROMs that support Master Serial,Slave Serial, Master SelectMAP, and Slave SelectMAP FPGA configuration modes (Figure 2). A summary of the Platform Flash PROM family members and supported features is shown in Table 1.
Features
(1) In-System Programmable PROMs for Configuration of Xilinx FPGAs;
(2) Low-Power Advanced CMOS NOR FLASH Process;
(3) Endurance of 20,000 Program/Erase Cycles;
(4) Operation over Full Industrial Temperature Range (0C to +85C);
(5) IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) Support for Programming, Prototyping, and Testing;
(6) JTAG Command Initiation of Standard FPGA Configuration;
(7) Cascadable for Storing Longer or Multiple Bitstreams;
(8) Dedicated Boundary-Scan (JTAG) I/O Power Supply (VCCJ;
(9) I/O Pins Compatible with Voltage Levels Ranging From 1.5V to 3.3V ;
(10) Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages;
(11) XCF01S/XCF02S/XCF04S - 3.3V supply voltage - Serial FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO20 and VOG20 packages.XCF08P/XCF16P/XCF32P - 1.8V supply voltage - Serial or parallel FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO48, VOG48, FS48,and FSG48 packages;- Design revision technology enables storing and accessing multiple design revisions for configuration Built-in data decompressor compatible with Xilinx advanced compression technolog to 3.3V ;
(10) Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages;
(11) XCF01S/XCF02S/XCF04S - 3.3V supply voltage - Serial FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO20 and VOG20 packages.XCF08P/XCF16P/XCF32P - 1.8V supply voltage - Serial or parallel FPGA configuration interface (up to 33 MHz) - Available in small-footprint VO48, VOG48, FS48,and FSG48 packages;- Design revision technology enables storing and accessing multiple design revisions for configuration Built-in data decompressor compatible with Xilinx advanced compression technolog.
