Product Summary

description/ordering information:These octal edge-triggered D-type flip-flops feature 3-state outputs designed specifically for
bus driving. They are particularly suitable for implementing buffer registers, I/O ports, bidirectional bus drivers, and working registers.
The eight flip-flops enter data on the low-to-high transition of the clock (CLK) input. A buffered output-enable (OE) input can be used
to place the eight outputs in either a normal logic state (high or low logic levels) or the high-impedance state. In the high-impedance
state, the outputs neither load nor drive the bus lines significantly. The high-impedance state and increased drive provide the capability to drive bus
lines without interface or pullup components.

Parametrics

absolute maximum ratings over operating free-air temperature range (unless otherwise noted)?
Supply voltage range, VCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –0.5 V to 7 V
Input clamp current, IIK (VI < 0 or VI > VCC) (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±20 mA
Output clamp current, IOK (VO < 0 or VO > VCC) (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±20 mA
Continuous output current, IO (VO = 0 to VCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±35 mA
Continuous current through VCC or GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±70 mA
Package thermal impedance, θJA (see Note 2): DB package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70°C/W
DW package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58°C/W
N package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69°C/W
NS package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60°C/W
PW package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83°C/W
Storage temperature range, Tstg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . –65°C to 150°C

Features

Feature :

(1) Wide Operating Voltage Range of 2 V to 6 V;

(2) High-Current 3-State Noninverting Outputs Drive Bus Lines Directly or Up To 15 LSTTL Loads;
(3) Low Power Consumption, 80-μA Max ICC;
(4) Typical tpd = 22 ns;
(5) ±6-mA Output Drive at 5 V;
(6) Low Input Current of 1 μA Max;
(7) Bus-Structured Pinout
