Product Summary
DESCRIPTION:The TDA7297 is a dual bridge amplifier specially
designed for TV and Portable Radio applications
Parametrics
ABSOLUTE MAXIMUM RATINGS
VS Supply Voltage 20 V
IO Output Peak Current (internally limited) 2 A
Ptot Total Power Dissipation (Tcase = 70°C) 33 W
Top Operating Temperature 0 to 70 °C
Tstg, Tj Storage and Junction Temperature -40 to +150 °C
Features
WIDE SUPPLY VOLTAGE RANGE (6V -18V)
MINIMUM EXTERNAL COMPONENTS
– NO SWR CAPACITOR
– NO BOOTSTRAP
– NO BOUCHEROT CELLS
– INTERNALLY FIXED GAIN
STAND-BY & MUTE FUNCTIONS
SHORT CIRCUIT PROTECTION
THERMAL OVERLOAD PROTECTION
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TDA7297 |
STMicroelectronics |
Audio Amplifiers 15W Dual Bridge Amp |
Data Sheet |
|
|
||||||||||||
|
TDA7297D |
STMicroelectronics |
Audio Amplifiers 10W/10W DUAL BRIDGE AMP |
Data Sheet |
Negotiable |
|
||||||||||||
|
TDA7297D13TR |
STMicroelectronics |
Audio Amplifiers 10W/10W DUAL BRIDGE AMP |
Data Sheet |
Negotiable |
|
||||||||||||
|
TDA7297SA |
STMicroelectronics |
Audio Amplifiers 10W, 10W Dual Bridge 6V - 18V Portable |
Data Sheet |
|
|
||||||||||||
