8ch Darlington Sink Driver
The ULN2803APG / AFWG Series are high-voltage, high-current darlington drivers comprised of eight NPN darlington pairs.
All units feature integral clamp diodes for switching inductive loads.
Applications include relay, hammer, lamp and display (LED)
drivers
Parametrics
Absolute Maximum Ratings (Ta = 25°C):
Output sustaining voltage VCE (SUS) :-0.5 to 50 V
Output current : IOUT 500 mA / ch
Input voltage VIN :-0.5 to 30 V
Clamp diode reverse voltage VR :50 V
Clamp diode forward current IF :500 mA
Power dissipation APG PD :1.47 W
Power dissipation AFWG PD : 0.92 / 1.31 (Note) W
Operating temperature Topr :-40 to 85 °C
Storage temperature Tstg :-55 to 150 °C
Features
Features
? Output current (single output) 500 mA (max)
? High sustaining voltage output 50 V (min)
? Output clamp diodes
? Inputs compatible with various types of logic.
? Package Type-APG : DIP-18pin
? Package Type-AFWG : SOP-18pin
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ULN2803AFWG(5,EL,M |
Toshiba |
Transistors Darlington 8CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2803AFWG(5,M) |
Toshiba |
Transistors Darlington 8CH. 50V/.5A IFD IC |
Data Sheet |
Negotiable |
|
||||||||||||
|
ULN2803AFWG(O,EL,M |
Toshiba |
Transistors Darlington 8ch 500mA 50V 2.7k Ohm 5V -40/85 |
Data Sheet |
|
|
||||||||||||
 |
ULN2803AFWG(C,ELHA |
Toshiba |
Transistors Darlington 8ch 500mA 50V 2.7k Ohm 5V -40/85 |
Data Sheet |
|
|
||||||||||||
|
ULN2803AFWG(O,M) |
Toshiba |
Transistors Darlington 8-ch 500mA 50V 2.7 kOhm 5V CMOS |
Data Sheet |
Negotiable |
|
||||||||||||
