Product Summary

Description:This 7.62 mm (0.3 inch) LED seven-segment display uses industry standard size package and pinout. The device is available in either common anode or common cathode. The choice of colors includes High Efficiency
Red (HER), Green, AlGaAs Red, and Yellow. The gray face displays are suitable for indoor use.

Parametrics

Absolute Maximum Ratings at TA = 25℃
Power Dissipation Segment HER HDSP-33xE:65mW,Green HDSP-33xG:65mW,ALGaAs Red HDSP-33xA:30mW,Yellow HDSP-33xY:52mW
Forward Current Segment HER HDSP-33xE:25[1]mA,Green HDSP-33xG:25[2]mA,ALGaAs Red HDSP-33xA:15[3]mA,Yellow HDSP-33xY:20[4] mA
Peak Forward Current per Segment (1/10 Duty Factor at 10 kHz)HER HDSP-33xE:100mA,Green HDSP-33xG:100mA,ALGaAs Red HDSP-33xA: 80mA,Yellow HDSP-33xY: 80 mA
Operating Temperature Range HER HDSP-33xE:–35 to +85℃ ,Green HDSP-33xG:–35 to +85℃ ,ALGaAs Red HDSP-33xA:–35 to +85℃ ,Yellow HDSP-33xY:–35 to +85 ℃
Storage Temperature Range HER HDSP-33xE:–35 to +85℃ ,Green HDSP-33xG:–35 to +85℃ ,ALGaAs Red HDSP-33xA:–35 to +85 ℃,Yellow HDSP-33xY:–35 to +85 ℃
Reverse Voltage per Segment or DP HER HDSP-33xE:5V,Green HDSP-33xG: 5V,ALGaAs Red HDSP-33xA: 5V,Yellow HDSP-33xY:5V
Wave Soldering Temperature for 3 Seconds HER HDSP-33xE:250℃,Green HDSP-33xG: 250℃,ALGaAs Red HDSP-33xA:250℃,Yellow HDSP-33xY: 250 ℃

Features

Features as below :
(1) Industry standard size;
(2) Industry standard pinout: 7.62 mm (0.4 inch) character height DIP lead on 2.54 mm;
(3) Choice of colors:High Efficiency Red (HER), Green,AlGaAs Red, and Yellow;
(4) Excellent appearance:Evenly lighted segments gray package gives optimum contrast± 50° viewing angle;
(5) Design flexibility:Common anode or common cathode Single digit Left and right hand decimal point;
(6) Categorized for luminous intensity:Green and yellow categorized for color.
