Product Summary
General Description:The HT78XX series of positive, linear regulators features low quiescent current (5 A typ.) with low dropout voltage, making them ideal for battery applications. The devices are capable of supplying 500mA of output current continuously.
They are available with several fixed output voltages ranging from 1.8V to 5.0V. Although designed primarily as fixed voltage regulators, these devices can be used with external components to obtain variable voltages and currents.
These rugged devices have Thermal Shutdown and Current Limiting to prevent device failure under the Worst of operating conditions.
Parametrics
Absolute Maximum Ratings*
Maximum Supply Voltage ............................ up to 8.5V
Storage Temperature .......................... -50℃ to 125℃
Operating Temperature ......................... -40℃ to 85℃
Features
Features:
Output voltage ranges: Fixed range of 1.8V, 2.5V,2.7V, 3.0V, 3.3V, 5.0V type.
Highly accuracy: 2%
Low voltage drop: 360mV (typ.),VOUT=5.0V at 500mA
Guaranteed output current: 500mA
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
HT7850 |
Other |
Data Sheet |
Negotiable |
|
||||||
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
HT7818 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7825 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7827 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7830 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7833 |
Other |
Data Sheet |
Negotiable |
|
||||||
HT7850 |
Other |
Data Sheet |
Negotiable |
|
