Product Summary

The LM2936M-5.0ultra-low quiescent current regulator features low dropout voltage and low current in the standby mode. The LM2936M-5.0 is ideally suited for automotive and other battery operated systems. The LM2936M-5.0 retains all of the features that are common to low dropout regulators including a low dropout PNP pass device, short circuit protection, reverse battery protection, and thermal shutdown.

Parametrics

LM2936M-5.0 absolute maximum ratings: (1) Input Voltage (Survival): +60V, -50V; (2) ESD Susceptibility: 2000V; (3) Power Dissipation: Internally limited; (4) Junction Temperature (TJmax) : 150°C ; (5) Storage Temperature Range: -65°C to +150°C ; (6) Lead Temperature (Soldering, 10 sec.) : 260°C ; (7) Operating Temperature Range: -40 °C to +125°C ; (8) Maximum Input Voltage (Operational) : 40V.

Features

LM2936M-5.0 features: (1) Ultra low quiescent current (IQ ≤ 15 µA for IO ≤ 100 µA; (2) Fixed 5V, 50 mA output; (3) Output tolerance ±3% over line, load, and temperature; (4) Dropout voltage typically 200 mV @ I = 50 mA; (5) Reverse battery protection; (6) -50V reverse transient protection ; (7) Internal short circuit current limit; (8) Internal thermal shutdown protection; (9) 40V operating voltage limit.

Diagrams

LM2936M-5.0 Connection Diagram
