Product Summary
The MC144898 is a flexible light-emitting-diode driver which directly interfaces to individual lamps, 7-segment displays, or various combinations of
both. LEOs wired with common cathodes are driven in a multiplexed-by-5
fashion. Communication with an MCUIMPU is established through a synchronous serial port. The MC 144898 features data retention plus decode and scan
circuitry, thus relieving processor overhead. A single, current-setting resistor
is the only ancillary component required.
Parametrics
Maximum ratings
Vdd DC Supply voltage :-0.5 to + 6.0 V
Vin DC Input voltage : -0.5 to VDD + 0.5V
Vout DC Output Voltage : -0.5 to VDD + 0.5 V
I in DC input Cureent-per pin(includes pin 8) : ±15mA
Features
.Operating Voltage Range of Drive Circuitry: 4.5 to 5.5 V
.Operating Junction Temperature Range: -40° to 130°C
.Current Sources Controlled by Single Resistor Provide Anode Drive
.Low-Resistance FET Switches Provide Direct Common Cathode Interface
.Low-Power Mode (Extinguishes the LEDs) and Brightness Controlled via Serial Port
.Special Circuitry Minimizes EMI when Display is Driven and Eliminates EMI in Low-Power Mode
.Power-On Reset (POR) Blanks the Display on Power-Up, Independent of Supply Ramp Up Time
.May Be Used with Double-Heterojunction LEDs for Optimum Efficiency
.Chip Complexity: 4300 Elements (FETs, Resistors, Capacitors, etc.
