Product Summary

The PM6650-2M device also interfaces directly with the first in powerOne series power management ICs of the QCT. The PM6650-2M solution provides battery management and charging functions, including a USB charging option, and voltage regulation for the various MSM power regimes, the radioOne chipset and all other MSM-supported peripheral features. The PM6650-2M chip offers unparalleled integration of power management functions for CDMA terminals, affording a tremendous savings in size and BOM for handset design.

Parametrics

PM6650-2M ratings: (1) Integrated sereo:44.1 kHZ and 48 kHZ wideband codes capable of CD-qualit playback; (2) 409-pin 0.5 mm pitch CSP packaging technology:14mm x 14mm.

Features

PM6650-2M features: (1) CDMA2000 1X support(Revicion D and A) ;(2) High-performance ARM926EJ-S microprocessor core with memory management unit (MMU) ; (3) ARM Jazelle Jave hardware acceleration for laster Java-based games and other applets; (4) QDSP4000 high-performance DSP cores;(5) 72-polyphony MIDI wavetable synthesizer for high-quality mucis playback through the MSM6150 INTEGRATED wideband codec; (6) Quarter Video Graphics Array (QVGA) and Connmon intermadate Format (CIF) resolution for LCD; (7) Video telephony at 15 frames per second(fps),CIF resolution, (8)Video encode at 15 fps CIF for camcorder capability.

Diagrams

PM6650-2M Block Diagram
