Product Summary
45A, 60V, 0.028 Ohm, Logic Level
N-Channel Power MOSFETs
These are N-Channel enhancement mode power MOSFETs
manufactured using the latest manufacturing process
technology. This process, which uses feature sizes
approaching those of LSI circuits, gives optimum utilization
of silicon, resulting in outstanding performance. They were
designed for use in applications such as switching
regulators, switching converters, motor drivers, and relay
drivers. These transistors can be operated directly from
integrated circuits.
Formerly developmental type TA49177
Parametrics
Absolute Maximum Ratings TC = 25℃, Unless Otherwise Specified
Drain to Source Voltage (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VDSS 60 V
Drain to Gate Voltage (RGS = 20kΩ) (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VDGR 60 V
Gate to Source Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VGS ±10 V
Continuous Drain Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ID 45A
Pulsed Drain Current (Note 3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .IDM Refer to Peak Current Curve
Pulsed Avalanche Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EAS Refer to UIS Curve
Power Dissipation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . PD 142W
Derate Above 25℃ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.95W/℃
Operating and Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . TJ, TSTG -55 to 175℃
Maximum Temperature for Soldering
Leads at 0.063in (1.6mm) from Case for 10s. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TL 300℃
Package Body for 10s, See Techbrief 334 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tpk 250℃
Features
Features
? 45A, 60V
? rDS(ON) = 0.028Ω
? Temperature Compensating PSPICE? Model
? Peak Current vs Pulse Width Curve
? UIS Rating Curve
? 175℃ Operating Temperature
? Related Literature
- TB334 “Guidelines for Soldering Surface MountComponents to PC Boards
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||
---|---|---|---|---|---|---|---|---|---|---|
RFP45N06 |
Fairchild Semiconductor |
MOSFET TO-220AB N-Ch Power |
Data Sheet |
Negotiable |
|
|||||
RFP45N06_Q |
Fairchild Semiconductor |
MOSFET TO-220AB N-Ch Power |
Data Sheet |
Negotiable |
|
|||||
RFP45N06LE |
Other |
Data Sheet |
Negotiable |
|
