Product Summary
Description:The TSV358 and TSV324 (dual & quad) are low voltage versions of LM358 and LM324 commodity operational amplifiers. TSV321 is the single
version. The TSV321/358/324 are able to operate with voltage as low as 2.5V and features both I/O rail-to-rail.
The common mode input voltage extends 200mV at 25°C beyond the supply voltages while the output voltage swing is within 100mV of each rail
with 600 Ohm load resistor. These devices offer 1.3MHz of gain-bandwidth product and provide high output drive capability typically at 65mAload.
These performances make the TSV3xx family ideal for active filters, general purpose low-voltage applications, general purpose portable devices
Parametrics
Absolute Maximum Ratings
VCC Supply Voltage (1): 7V
Vid Differential Input Voltage (2) :±1 V
Vi Input Voltage: VDD-0.3 to VCC +0.3 V
Tstg Storage Temperature: -65 to +150 °C
Tj Maximum Junction Temperature :150 ℃
Features
Operating at VCC = 2.5V to 6V
Rail-to-rail input & output
Extended Vicm (VDD - 0.2V to VCC + 0.2V)
Capable of driving a 32Ω load resistor
High stability: 500pF
Available in SOT23-5 micropackage
Operating temperature range: -40, +125℃
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TSV358IPT |
STMicroelectronics |
Operational Amplifiers - Op Amps Dual Rail-to-Rail Low Power |
Data Sheet |
|
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
 |
TSV321 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
|
TSV321ID |
STMicroelectronics |
Operational Amplifiers - Op Amps Gen purpose input output Lo pwr |
Data Sheet |
|
|
||||||||||||
|
TSV321IDT |
STMicroelectronics |
Operational Amplifiers - Op Amps Single Rail-to-Rail Low Power |
Data Sheet |
|
|
||||||||||||
|
TSV321RAILT |
STMicroelectronics |
Operational Amplifiers - Op Amps Gen purpose input output Lo pwr |
Data Sheet |
|
|
||||||||||||
|
TSV321RAIYLT |
STMicroelectronics |
Operational Amplifiers - Op Amps Gen Purp LV RR 2.5V to 6V 32Ohm 500pF |
Data Sheet |
|
|
||||||||||||
|
TSV321RILT |
STMicroelectronics |
Operational Amplifiers - Op Amps Gen purpose input output Lo pwr |
Data Sheet |
|
|
||||||||||||
