Product Summary
The timer control circuit, U2100B, uses bipolar technology. The U2100B has different mode selections (Zero voltage switch, Phase control, Relay control). The U2100B can be used in triac application for two or three wire system as a power switch. Applications of the U2100B include: Motion detectors,Touch sensors and Timer.
Parametrics
U2100B absolute maximum ratings: (1) Supply current IS: 10mA; (2) Peak currentt 10≤ μs, is: 60mA; (3) Supply voltage Vs: 32V; (4) Reference voltage source Output current Io: 3mA; (5) Synchronization Input current t≤10μs, ±ISync: 5mA, iSync.: 20mA; (6) Storage temperature range Tstg: -40°C to +125°C; (7) Junction temperature Tstg: 125°C; (8) Ambient temperature range Tamb: 0°C to 100°C.
Features
U2100B features: (1) Adjustable and retriggerable tracking time; (2) Window monitoring for sensor input; (3) Enable input for triggering; (4) Internal noise suppression (40 ms) and retrigge blocking (640 ms) ; (5) Two or three wire application.
Diagrams
lt=
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 U2100B-MFPG3Y |
Atmel |
Timers & Support Products Sensor Ctrl. Timer for triac or relay |
Data Sheet |
|
|
||||||||
|
U2100B-MFPY |
Atmel |
Timers & Support Products Sensor Ctrl. Timer for triac or relay |
Data Sheet |
|
|
||||||||
|
U2100B-MY |
Atmel |
Timers & Support Products Sensor Ctrl. Timer for triac or relay |
Data Sheet |
|
|
||||||||
|
U2100B-MFPG3 |
|
IC TIMER CTRLR TRIAC/RELAY 8SOIC |
Data Sheet |
Negotiable |
|
||||||||
 |
U2100B |
Other |
|
Data Sheet |
Negotiable |
|
||||||||
|
U2100B-MFP |
|
IC TIMER CTRLR TRIAC/RELAY 8SOIC |
Data Sheet |
Negotiable |
|
||||||||
|
U2100B-M |
|
IC TIMER CTRLR TRIAC/RELAY 8-DIP |
Data Sheet |
Negotiable |
|
||||||||
