8ETX06

8ETX06 - Hyperfast Rectifier - International Rectifier

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.35 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	0.35 / Piece
10 ~ 100 :	0.33 / Piece
100 ~ 1000 :	0.30 / Piece

PartNumber:: 8ETX06

Brand:: International Rectifier - IR | D/C: 10+

Availability:: Supply Ability: 10000/Month Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Chaney's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-28

From Other Seller

Part Number:8ETX06
US $0.30 - 0.35
Quantity:

piece

Product Summary

Description/ Applications:State of the art Hyperfast recovery rectifiers designed with optimized performance of forward voltage drop, Hyperfast
recover time, and soft recovery.The planar structure and the platinum doped life time control guarantee the best overall performance, ruggedness and reliability characteristics.
These devices are intended for use in PFC Boost stage in the AC-DC section of SMPS, inverters or as freewheeling diodes. The IR extremely optimized stored charge and low recovery current minimize the switching losses and reduce over dissipation in the switching element and snubbers

Parametrics

Absolute Maximum Ratings
VRRM Peak Repetitive Reverse Voltage 600 V
IF(AV) Average Rectified Forward Current @ TC = 143°C , @ TC = 106°C (FULLPACK)8 A
IFSM Non Repetitive Peak Surge Current @ TJ = 25°C 110 A
IFM Peak Repetitive Forward Current 18 A
TJ, TSTG Operating Junction and Storage Temperatures - 65 to 175℃

Features

Feature:
(1)Hyperfast Recovery Time;
(2)Low Forward Voltage Drop;
(3)Low Leakage Current;
(4)175°C Operating Junction Temperature;
(5)UL E78996 approved
