Product Summary

Trans IGBT Module N-CH 600V 150A 42-Pin ECONO 3

Parametrics

IGBT-Wechselrichter / IGBT-inverter Vorl?ufige Daten / preliminary data
H?chstzul?ssige Werte / maximum rated values:
Kollektor-Emitter-Sperrspannung collector-emitter voltage Tvj=25℃ ,Vces :600V
Kollektor-Dauergleichstrom DC-collector current TC=55℃，Tvj=175℃，IC nom :150A
Periodisher Kollektor Spitzenstrom repetitive peak collector current tp=1ms ,Icrm :300A
Gesamt-Verlustleistung total power disslpation Tc=25℃,Tjv=175℃，Plgt :430W
Gate-Emitter-Spitzenspannung gate-emitter peak voltage Vges :+/-20V

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
FS150R06KE3
FS150R06KE3
Infineon Technologies
IGBT Modules IGBT MODULES 600V
Data Sheet
0-5: $128.50
5-10: $109.22
