Product Summary

This technical information specifies semiconductor devices but promises no charateristics.
No warranty or guarantee,expressed or implied is made regarding delivery, performace or suitability

Parametrics

Absolute Maximum Ratings:
Vs1 stabllized 15V power supply :18V
Vs2 ynstabllized 24V power supply :30V
ViH input signal voltage(high): 15+0.3V
dv/dt secondary to primary side : 75kV/μs
V isollO input/output(AC.r.m.s .2s) :2500Vac
Viso112 output 1/output 2(AC.r.m.s .2s) :1500Vac
Fmax switching frequency :20kHz
Top(Tsig) operating/storage temperature :-25...+85℃

Features

Features as below:
(1)SKiiP technology inside ;
(2)Low loss IGBTs;
(3)CAL diode technology;
(4)Integrated current sensor;
(5)Integrated heat sink;
(6)IEC 60721-3-3(humidity) class 3K3/IE32(SKiiP 2System);
(7)IEC 68T.1(climate)40/125/56(SKiip 2power section)
