Product Summary

DESCRIPTION:Schottky barrier rectifier designed for high frequency miniature Switched Mode Power Supplies such as adaptators and on board
DC/DC converters. Packaged in TO-220AB, TO-220FPAB, D2PAK and I2PAK

Parametrics

ABSOLUTE RATINGS (limiting values, per diode)
VRRM Repetitive peak reverse voltage 100 V
IF(RMS) RMS forward current 10 A
IF(AV) Average forward TO-220AB Tc = 165°C per diode 5A
IF(AV) current δ = 0.5 D2 PAK / I2PAK Tc = 165°C per device 10A
TO-220FPAB Tc = 160°C
IFSM Surge non repetitive forward current tp = 10 ms sinusoidal 180 A
IRRM Repetitive peak reverse current tp = 2 μs square F = 1kHz 1 A
PARM Repetitive peak avalanche power tp = 1μs Tj = 25°C 7200 W
Tstg Storage temperature range - 65 to + 175 °C
Tj Maximum operating junction temperature * 175 °C
dV/dt Critical rate of rise of reverse voltage 10000 V/μs

Features

FEATURES AND BENEFIT
(1) HIGH JUNCTION TEMPERATURE CAPABILITY FOR CONVERTERS LOCATED IN CONFINED ENVIRONMENT;
(2) LOW LEAKAGE CURRENT AT HIGH TEMPERATURE;
(3) LOW STATIC AND DYNAMIC LOSSES AS A RESULT OF THE SCHOTTKY BARRIER;
(4) AVALANCHE CAPABILITY SPECIFIED

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STPS10H100CT
STPS10H100CT

STMicroelectronics

Schottky (Diodes & Rectifiers) 2X5 Amp 100 Volt

Data Sheet

0-1: $0.46
1-10: $0.41
10-100: $0.34
100-250: $0.33
