Product Summary
DESCRIPTION
The L6219 is a bipolar monolithic integrated circuits intended to control and drive both winding of
a bipolar stepper motor or bidirectionally control
two DC motors.
The L6219 with a few external components form
a complete control and drive circuit for LS-TTL or
microprocessor controlled stepper motor system.
The power stage is a dual full bridge capable of
sustaining 46V and including four diodes for current recirculation.
A cross conduction protection is provided to avoid
simultaneous cross conduction during switching
current direction.
An internal pulse-width-modulation (PWM) controls the output current to 750mA with peak startup current up to 1A.
Wide range of current control from 750mA (each
bridge) is permitted by means of two logic inputs
and an external voltage reference. A phase input
to each bridge determines the load current direction.
A thermal protection circuitry disables the outputs
if the chip temperature exceeds safe operating
limits
Parametrics
ABSOLUTE MAXIMUM RATINGS:
VS Supply Voltage :50 V
Io Output Current (peak) :±1 A
Io Output Current (continuous) :±0.75 A
VSS Logic Supply Voltage :7 V
VIN Logic Input Voltage Range :-0.3 to +7 V
Vsense Sense Output Voltage :1.5 V
TJ Junction Temperature :+150 °C
To p Operating Temperature Range :0 to 70 °C
Tstg Storage Temperature Range :-55 to +150 °C
Features
(1)ABLE TO DRIVE BOTH WINDINGS OF BIPOLAR STEPPER MOTOR;
(2)OUTPUT CURRENT UP TO 750mA EACH WINDING;
(3)WIDE VOLTAGE RANGE 10V TO 46V;
(4)HALF-STEP, FULL-STEP AND MICROSTEPPING MODE; (5)BUILT-IN PROTECTION DIODES;
(6)INTERNAL PWM CURRENT CONTROL;
(7)LOW OUTPUT SATURATION VOLTAGE;
(8)DESIGNED FOR UNSTABILIZED MOTOR SUPPLY VOLTAGE;
(9)INTERNAL THERMAL SHUTDOWN
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 L6219DS |
STMicroelectronics |
Motor / Motion / Ignition Controllers & Drivers Dual Stepper Motor |
Data Sheet |
Negotiable |
|
||||||
|
L6219R013TR |
STMicroelectronics |
Motor / Motion / Ignition Controllers & Drivers Dual Stepper Motor |
Data Sheet |
Negotiable |
|
||||||
|
L6219R |
STMicroelectronics |
Motor / Motion / Ignition Controllers & Drivers Dual Stepper Motor |
Data Sheet |
Negotiable |
|
||||||
 |
L6219DSTR-T |
|
IC MOTOR DRIVER PWM DUAL 24-SOIC |
Data Sheet |
Negotiable |
|
||||||
|
L6219DSTR |
|
IC MOTOR DRVR PWM DUAL 24SOIC |
Data Sheet |
Negotiable |
|
||||||
|
L6219DS-T |
|
IC MOTOR DRVR PWM DUAL 24SOIC |
Data Sheet |
|
|
||||||
|
L6219DSA13TR |
STMicroelectronics |
Motor / Motion / Ignition Controllers & Drivers Dual Stepper Motor |
Data Sheet |
Negotiable |
|
||||||
|
L6219DSA |
STMicroelectronics |
Motor / Motion / Ignition Controllers & Drivers Dual Stepper Motor |
Data Sheet |
Negotiable |
|
||||||
