Product Summary

Overview:The LA4451 is a single package two channel power IC that supports an operating voltage of 26 V. It is particularly well suited for use as the bus or track power IC in
car stereo applications. Additionally, since the LA4450 can drive 4 Ω loads, it can be used effectively in highpower high-end products. Furthermore, since it supports a
high operating voltage and has low distortion, it is also optimal for use in TV and home audio products

Parametrics

Maximum Ratings at Ta = 25℃
Maximum supply voltage VCC max Rg = 0 (no signal) 37 V
Maximum output current IO peak 4 A
Allowable power dissipation Pd max* Infinite heat sink 25 W
Operating temperature Topr –35 to +80 °C
Storage temperature Tstg –40 to +150 ℃

Features

Features
? Two channels in a single package
? PO = 12 W × 2 (VCC = 26.4 V, RL= 8 Ω, THD = 10%)
? PO = 20 W × 2 (VCC = 26.4 V, RL= 4Ω, THD = 10%)
? Can drive 4 Ω speakers
? Built-in standby switch
? Minimizes impulse noises
