Product Summary
General Description:The LM79XX series of 3-terminal regulators is available with fixed output voltages of b5V, b8V, b12V, and b15V.
These devices need only one external componentDa com-pensation capacitor at the output. The LM79XX series is packaged in the TO-220 power package and is capable of
supplying 1.5A of output current.These regulators employ internal current limiting safe area protection and thermal shutdown for protection against vir-
tually all overload conditions.Low ground pin current of the LM79XX series allows output voltage to be easily boosted above the preset value with a
resistor divider. The low quiescent current drain of these devices with a specified maximum change with line and load ensures good regulation in the voltage boosted
mode.For applications requiring other voltages, see LM137 data
sheet。
Parametrics
Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales
Office/Distributors for availability and specifications.
Input Voltage
(Vo e b5V) -25V
(Vo e b12V and b15V) -35V
Input-Output Differential
(Vo e b5V) 25V
(Vo e b12V and b15V) 30V
Power Dissipation (Note 2) Internally Limited
Operating Junction Temperature Range 0℃ to a125℃
Storage Temperature Range -65℃ to +150℃
Lead Temperature (Soldering, 10 sec.) 230℃
Features
Features
(1) Thermal, short circuit and safe area protection;
(2) High ripple rejection;
(3) 1.5A output current;
(4) 4% tolerance on preset output voltage
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM7915CT |
Fairchild Semiconductor |
Linear Regulators - Standard 3-Term 1A Negative Voltage Regulator |
Data Sheet |
|
|
||||||||||||
|
LM7915CT/NOPB |
National Semiconductor (TI) |
Linear Regulators - Standard 3-Terminal Neg Vltg |
Data Sheet |
|
|
||||||||||||
