Product Summary

DESCRIPTION:The SG2000 series integrates seven NPN Darlington pairs with internal suppression diodes to drive lamps, relays, and solenoids in
many military, aerospace, and industrial applications that require severe environments.  All units feature open collector outputs with
greater than 50V breakdown voltages combined with 500mA current carrying capabilities.  Five different input configurations
provide optimized designs for interfacing with DTL, TTL, PMOS, or CMOS drive signals.  These devices are designed to operate from
-55°C to 125°C ambient temperature in a 16 pin dual in line ceramic (J) package and 20 pin Leadless Chip Carrier (LCC).  The plastic dual in–line (N) is designed to operate over the commercial emperature range of 0°C to 70°C

Parametrics

Output Voltage, VCE
(SG2000, 2010 series) ................................................50V
(SG2020 series) .................................................95V
Input Voltage, VIN(SG2002,3,4) .....................................30V
Continuous Input Current, IIN........................................25mA

Features

FEATURES
? Seven npn Darlington pairs
? -55°C to 125°C ambient operating temperature range
? Collector currents to 600mA
? Output voltages from 50V to 95V
? Internal clamping diodes for inductive loads
? DTL, TTL, PMOS, or CMOS compatible inputs
? Hermetic ceramic package
