Product Summary

Description:The LD29300xx is a high current, high accuracy,  low-dropout voltage regulator series. These
regulators feature 400 mV dropout voltage and very low ground current. Designed for high current loads, these devices are also used in
lower current, extremely low dropout-critical systems, where their tiny dropout voltage and ground current values are important attributes.
Typical applications are in power supply switching post regulation, Series power supply for monitors, Series power supply for VCRs and TVs,
Computer systems and Battery powered systems

Parametrics

Absolute maximum ratings
VI DC input voltage 30 (1)V
IO Output current Internally limited mA
PD Power dissipation Internally limited mW
TSTG Storage temperature range -55 to 150 °C
TOP Operating junction temperature range -40 to 125 °C

Features

Features
(1) Very low dropout voltage (Typ. 0.4 at 3 A);
(2) Guaranteed output current up to 3 A;
(3) Fixed voltage with ± 1 % tolerance at 25 °C;
(4) Internal current and thermal limit;
(5) Logic controlled electronic shutdown available in PPAK
