Product Summary
Mechanical Characteristics:
? Case: Epoxy, Molded
? Weight: 1.1 Gram (Approximately)
? Finish: All External Surfaces Corrosion Resistant and Terminal Leads are Readily Solderable
? Lead Temperature for Soldering Purposes:260°C Max. for 10 Seconds
? Polarity: Cathode indicated by Polarity Band
Parametrics
MAXIMUM RATINGS
Average Rectified Forward Current (Square Wave)(Mounting Method #3 Per Note 2)IF(AV) 4.0 @ TA = 80°C 4.0 @TA = 40°C A
Nonrepetitive Peak Surge Current(Surge applied at rated load conditions, half wave, single phase, 60 Hz)IFSM 125 110 A
Operating Junction Temperature & Storage Temperature TJ, Tstg 65 to +175℃
Features
Features
(1) Ultrafast 25 ns, 50 ns and 75 ns Recovery Times;
(2) 175°C Operating Junction Temperature;
(3) Low Forward Voltage;
(4) Low Leakage Current;
(5) High Temperature Glass Passivated Junction;
(6) Reverse Voltage to 600 V;
(7) Shipped in Plastic Bags, 500 per Bag;
(8) Available in Tape and Reel, 1500 per Reel, by Adding a “RL"Suffix to the Part Number;
(9) Pb-Free Packages are Available
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 MUR420 |
Taiwan Semiconductor |
Rectifiers 4A 200V |
Data Sheet |
|
|
||||||||||||||
 |
MUR420-E3/51 |
Vishay Semiconductors |
Rectifiers 200 Volt 4.0A 50ns 150 Amp IFSM |
Data Sheet |
Negotiable |
|
||||||||||||||
|
MUR420-E3/73 |
Vishay Semiconductors |
Rectifiers 200 Volt 4.0A 50ns 150 Amp IFSM |
Data Sheet |
|
|
||||||||||||||
|
MUR420RL |
ON Semiconductor |
Rectifiers 200V 4A UltraFast |
Data Sheet |
Negotiable |
|
||||||||||||||
|
MUR420RLG |
ON Semiconductor |
Rectifiers 200V 4A UltraFast |
Data Sheet |
|
|
||||||||||||||
|
MUR420SG |
ON Semiconductor |
Rectifiers UTLRAFAST REC |
Data Sheet |
Negotiable |
|
||||||||||||||
 |
MUR420-TP |
|
DIODE ULT FAST 4A 200V DO-201AD |
Data Sheet |
|
|
||||||||||||||
|
MUR420-E3/54 |
Vishay Semiconductors |
Rectifiers 200 Volt 4.0A 50ns 150 Amp IFSM |
Data Sheet |
|
|
||||||||||||||
