Product Summary
Mechanical Data
Case: Molded Plastic
Terminals: Plated Leads Solderable per MIL-STD-202, Method 208
Polarity: As Marked on Body
Marking: Type Number
Weight: 2.24 grams (approx.)
Mounting Position: Any
Parametrics
Maximum Ratings and Electrical Characteristics @ TA = 25 C unless otherwise specified
Average Rectified Output Current @ TC = 95℃(Note 1) IO 30 A
Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load(JEDEC Method) IFSM 275 A
Forward Voltage Drop @ IF = 15A, TC = 25 C VFM 0.55 0.70 V
Peak Reverse Current @ TC = 25℃ IRM 1.0 mA
at Rated DC Blocking Voltage @ TC = 100℃ IRM 75mA
Typical Junction Capacitance (Note 2) Cj 1100 pF
Typical Thermal Resistance Junction to Case (Note 1) R Jc 2.0 K/W
Operating and Storage Temperature Range Tj, TSTG -65 to +150 ℃
Features
Features
(1)Schottky Barrier Chip;
(2)Guard Ring Die Construction for Transient Protection;
(3)Low Power Loss, High Efficiency;
(4)High Surge Capability;
(5)High Current Capability and Low Forward Voltage Drop;
(6)For Use in Low Voltage, High Frequency Inverters, Free Wheeling, and Polarity Protection Application;
(7)Plastic Material : UL Flammability Classification Rating 94V-0
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SBL3040PT |
Diodes Inc. |
Schottky (Diodes & Rectifiers) 30A 40V |
Data Sheet |
Negotiable |
|
||||||||||||
|
SBL3040PT-E3/45 |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 30 Amp Dual Common-Cathode |
Data Sheet |
|
|
||||||||||||
