Product Summary
TYPICAL APPLICATIONS:
For use in low voltage, high frequency inverters,
freewheeling, DC/DC converters, and polarity protection
applications.
Parametrics
PRIMARY CHARACTERISTICS
IF(AV) :1.0 A
VRRM :20 V to 60 V
IFSM :40 A
VF :0.50 V, 0.75 V
TJ max. :125 °C, 150 °C
Features
FEATURES
? Low profile package
? Ideal for automated placement
? Guardring for overvoltage protection
? Low power losses, high efficiency
? Low forward voltage drop
? High surge capability
? Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
? AEC-Q101 qualified
? Material categorization: For definitions of compliance
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SS14/13T |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
SS14/2FT |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
SS14/2GT |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
SS14-E3/11T |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
|
|
|||||||||||||
SS14-E3/1T |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
SS14-E3/51T |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 40 Volt 1.0 Amp 40 Amp IFSM |
Data Sheet |
Negotiable |
|
|||||||||||||
SS14-E3/61T |
Vishay Semiconductors |
Schottky (Diodes & Rectifiers) 1.0 Amp 40 Volt |
Data Sheet |
|
|
|||||||||||||
SS14-TP |
Micro Commercial Components (MCC) |
Schottky (Diodes & Rectifiers) 1A, 40V |
Data Sheet |
|
|
