Product Summary

2N3055 transistor



Parametrics

ABSOLUTE  MAXIMUM  RATINGS:
VCBO collector-Base Voltage (Ie=0) value :100V
VCER Collector-Emitter Voltage(Rbe≤100Ω) value :70V
VCEO Collector-Emitter Voltage(Ib=0) value:60V
Vebo Emitter-Base Voltage(Ic=0) valye : 7V
Ic Collector Current value :15A
Ib Base Current value :7A
Plot Total Dissipation at Tc≤25℃ value:115W
Tstg Storage Temperature value:-65 to 200℃
Tj Max.Operating Junction Temperature value:200℃

Features

 STMicroelectronics PREFERRED SALESTYPES
n COMPLEMENTARY NPN-PNP DEVICE

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
2N3055
2N3055
STMicroelectronics
Transistors Bipolar (BJT) NPN Power Switching
Data Sheet
0-1: $1.08
1-10: $0.88
10-100: $0.74
100-250: $0.68
2N3055_MJ2955
2N3055_MJ2955
Other

Data Sheet
Negotiable
2N3055A
2N3055A
ON Semiconductor
Transistors Bipolar (BJT) 15A 60V 115W NPN
Data Sheet
Negotiable
2N3055AG
2N3055AG
ON Semiconductor
Transistors Bipolar (BJT) 15A 60V 115W NPN
Data Sheet
0-1: $1.54
1-25: $1.24
25-100: $1.10
100-500: $0.96
2N3055E
2N3055E
Other

Data Sheet
Negotiable
2N3055G
2N3055G
ON Semiconductor
Transistors Bipolar (BJT) NPN 15A 60V
Data Sheet
0-1: $1.38
1-25: $1.33
25-100: $1.02
100-500: $0.79
2N3055H
2N3055H
ON Semiconductor
Transistors Bipolar (BJT) 15A 60V 115W NPN
Data Sheet
Negotiable
2N3055HG
2N3055HG
ON Semiconductor
Transistors Bipolar (BJT) 15A 60V 115W NPN
Data Sheet
Negotiable
