Product Summary

DESCRIPTION:The L7900 series of three-terminal negative regulators is available in TO-220, ISOWATT220 TO-3 and D2 PAK packages and several fixed
output voltages, making it useful in a wide range of applications.These regulators can provide local on-card regulation, eliminating the distribution
problems associated with single point regulation;furthermore, having the same voltage option as the L7800 positive standard series, they are
particularly suited for split power supplies. In addition, the -5.2V is also available for ECL system. If adequate heat sinking is provided,
they can deliver over 1.5A output current. Although designed primarily as fixed voltage regulators, these devices can be used with
external components to obtain adjustable voltages and currents

Parametrics

ABSOLUTE MAXIMUM RATINGS
Vi DC Input Voltage (for VO = 5 to 18V): -35V
Vi DC Input Voltage (for VO = 20, 24V):-40V
Io Output Current Internally limited
Pt o  t Power Dissipation Internally limited
To p Operating Junction Temperature Range ：0 to 150℃
Ts t  g Storage Temperature Range ：- 65 to 150℃

Features

Feature :
(1) OUTPUT CURRENT UP TO 1.5 A;
(2) OUTPUT VOLTAGESOF -5; -5.2; -6; -8; -9;-12; -15; -18; -20; -22; -24V;
(3) THERMAL OVERLOAD PROTECTION;
(4) SHORT CIRCUIT PROTECTION;
(5) OUTPUT TRANSITION SOA PROTECTION

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
L7912CV
L7912CV
STMicroelectronics
Linear Regulators - Standard 12V 1.5A Negative
Data Sheet
0-1: $0.38
1-10: $0.28
10-100: $0.24
100-250: $0.21
L7912CV-DG
L7912CV-DG
STMicroelectronics
Linear Regulators - Standard POS Voltage Reg IC 3-Terminal 1.5A
Data Sheet
0-1: $0.38
1-10: $0.34
10-100: $0.26
100-250: $0.23
