Product Summary

TYPICAL APPLICATIONS
For use in high frequency inverters, switching power
supplies, freewheeling diodes, OR-ing diode, dc-to-dc
converters and reverse battery protection

Parametrics

MAXIMUM RATINGS (TA = 25 °C unless otherwise noted)
Maximum repetitive peak reverse voltage VRRM 100 V
Maximum average forward rectified current (Fig. 1) IF(AV) 30 A
Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load IFSM 250 A
Isolation voltage (ITO-220AB only)From terminal to heatsink t = 1 min VAC 1500 V
Operating junction and storage temperature range TJ, TSTG - 40 to + 150 °C

Features

FEATURES
 ? Trench MOS Schottky technology
 ? Low forward voltage drop, low power losses
 ? High efficiency operation
 ? Low thermal resistance
 ? Meets MSL level 1, per J-STD-020, LF maximum peak of 245 °C (for TO-263AB package)
 ? Solder dip 260 °C, 40 s (for TO-220AB, ITO-220AB,and TO-262AA package)
 ? Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
V30100S-E3/45
V30100S-E3/45
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 30 Amp 100 Volt Single TrenchMOS
Data Sheet
Negotiable
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
V30100S-E3/45
V30100S-E3/45
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 30 Amp 100 Volt Single TrenchMOS
Data Sheet
Negotiable
V30150C-E3/4W
V30150C-E3/4W
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 30 Amp 150 Volt Dual TrenchMOS
Data Sheet
0-1: $1.31
1-10: $1.15
10-100: $0.98
100-250: $0.88
V30120SG-E3/4W
V30120SG-E3/4W
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 30 Amp 120 Volt Single TrenchMOS
Data Sheet
0-1: $0.99
1-10: $0.86
10-100: $0.74
100-250: $0.66
V30120S-E3/4W
V30120S-E3/4W
Vishay Semiconductors
Schottky (Diodes & Rectifiers) 30 Amp 120 Volt Single TrenchMOS
Data Sheet
0-500: $0.71
500-1000: $0.63
1000-2000: $0.61
2000-5000: $0.59
