Product Summary
Description:The SPS product family is specially designed for an off-line SMPS with minimal external components. The SPS consist of
high voltage power SenseFET and current mode PWM controller IC. PWM controller features integrated fixed oscillator, under voltage lock out, leading edge blanking, optimized gate
turn-on/turn-off driver, thermal shut down protection, over voltage protection, temperature compensated precision current
sources for loop compensation and fault protection circuit. Compared to discrete MOSFET and controller or RCC switching converter solution, a SPS can reduce total component count,
design size, weight and at the same time increase & efficiency, productivity, and system reliability. It has a basic platform well
suited for cost effective design in either a flyback converter or a forward converter
Parametrics
Absolute Maximum Ratings:
Drain-source (GND) voltage (1) VDSS 800 V
Drain-Gate voltage (RGS=1MΩ) VDGR 800 V
Gate-source (GND) voltage VGS ±30 V
Drain current pulsed (2)IDM 12 ADC
Single pulsed avalanche energy (3)EAS 95 mJ
Avalanche current(4)IAS 6 A
Continuous drain current (TC=25°C) ID 3.0 ADC
Continuous drain current (TC=100°C) ID 2.1 ADC
Supply voltage VCC 30 V
Analog input voltage range VFB -0.3 to VSD V
Total power dissipationPD 35 W
Derating 0.28 W/°C
Operating temperature TOPR -25 to +85 °C
Storage temperature TSTG -55 to +150 °C
Features
Features
? Precision fixed operating frequency
? KA1L0380B/KA1L0380RB (50KHz)
? KA1M0380RB (67KHz)
? KA1H0380RB (100KHz)
? Pulse by pulse over current limiting
? Over load protection
? Over voltage protection (Min. 23V)
? Internal thermal shutdown function
? Under voltage lockout
? Internal high voltage sense FET
? Auto restart (KA1L0380RB/KA1M0380RB/KA1H0380RB
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 KA1M0380RB |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
KA1M0380RBTU |
Fairchild Semiconductor |
Power Switch ICs - Power Distribution |
Data Sheet |
Negotiable |
|
||||
|
KA1M0380RBYDTU |
Fairchild Semiconductor |
Power Switch ICs - Power Distribution |
Data Sheet |
Negotiable |
|
||||
|
KA1M0380RTU |
Fairchild Semiconductor |
Switch ICs - Various |
Data Sheet |
Negotiable |
|
||||
|
KA1M0380RYDTU |
Fairchild Semiconductor |
Switch ICs - Various |
Data Sheet |
Negotiable |
|
||||
