Product Summary

Description:The Z01 series is suitable for general purpose AC switching applications. These devices are typically used in applications such as home appliances (electrovalve, pump, door lock, small lamp control), fan speed controllers,...
Different gate current sensitivities are available, allowing optimized performance when driven directly through microcontrollers

Parametrics

 Absolute maximum ratings:
IT(RMS) On-state rms current(full sine wave) SOT-223 Ttab = 90 °C :1 A
IT(RMS) On-state rms current(full sine wave) TO-92 TL = 50 °C 1 A
IT(RMS) On-state rms current(full sine wave) SMBflat-3L Ttab = 107 °C 1 A
ITSM Non repetitive surge peak on-state F = 50 Hz t = 20 ms 8 A
ITSM current  (full cycle, Tj initial = 25 °C) F = 60 Hz t = 16.7 ms 8.5A
I2t I2t Value for fusing tp = 10 ms 0.35 A2s
dI/dt Critical rate of rise of on-state current IG = 2 x IGT , tr≤ 100 ns F = 120 Hz Tj = 125 °C 20 A/μs
IGM Peak gate current tp = 20 μs Tj
 = 125 °C 1 A
PG(AV) Average gate power dissipation Tj = 125 °C 1 W
Tstg Storage junction temperature range - 40 to + 150℃
Tj Operating junction temperature range - 40 to + 125℃

Features

Features
(1) On-state rms current, IT(RMS) 1 A;
(2) Repetitive peak off-state voltage, VDRM/VRRM 600 or 800 V;
(3) Triggering gate current, IGT (Q1) 3 to 25 mA
